ProductsThe IB_LS-1WR3 series products are specifically designed for applications in distributed power systems within circuit boards where isolation from the input power source is required. These products are applicable to pure digital circuits, general low-frequency analog circuits, relay-driven circuits, data exchange circuits, and other similar applications.
Model No | Nominal Voltage | Output Voltage/Current | Full Load Efficiency (%)② | Max Capacitive Load (μF) | |
Nominal Value (Range) | Voltage (VDC) | Current (mA) Max/Min | Typ | ||
IB0503LS-1WR3 | 5(4.5-5.5) | 3.3 | 250/25 | 67 | 2400 |
IB0505LS-1WR3 | 5 | 200/20 | 70 | 2400 | |
IB0512LS-1WR3 | 12 | 83/8 | 72 | 560 | |
IB0515LS-1WR3 | 15 | 67/7 | 73 | 560 | |
IB1203LS-1WR3 | 12(10.8-13.2) | 3.3 | 303/30 | 65 | 2400 |
IB1205LS-1WR3 | 5 | 200/20 | 70 | 2400 | |
IB1212LS-1WR3 | 12 | 83/8 | 72 | 560 | |
IB1215LS-1WR3 | 15 | 67/7 | 73 | 560 | |
IB1503LS-1WR3 | 15(13.5-16.5) | 3.3 | 303/30 | 65 | 2400 |
IB1505LS-1WR3 | 5 | 200/20 | 70 | 2400 | |
IB1512LS-1WR3 | 12 | 83/8 | 72 | 560 | |
IB1515LS-1WR3 | 15 | 67/7 | 73 | 560 | |
IB2405LS-1WR3 | 5 | 200/20 | 65 | 2400 | |
